Full Complement Single Row Cylindrical Roller Bearing: NCF2988V

Full Complement Single Row Cylindrical Roller Bearing: NCF2988V

Full Complement Single Row Cylindrical Roller Bearing
$16,211.89
EA

checkbox icon This item typically ship in 1-4 weeks.

checkbox icon Item listed as "Request For Quote" (RFQ) usually ship in 3-6 week

CAD
Specifications:
Attribute nameAttribute value
ConstructionFull Complement
Shaft Size440mm
D (mm)600
B (mm)95
C (lb)451868
C0 (lb)989164
Pu (lb)85428
Nr (RPM)430
Nmax (RPM)530
Weight(lbs)48.5
Code410583
Bore (mm)440
damin (mm)455
d1 (mm)474
SealsNone
ClearanceCN
Tmax (F)300
Tmin (F)-40
Material52100
Dbmax (mm)585
r1-r2 (mm)4
r3-r4 (mm)4
ramax (mm)3
rbmax (mm)3
k0.2
D1 (mm)545
smax (mm)6
das1 (mm)492
E (mm)525.5
PackageQTY1
UOMEA
Supports greater radial loads than an equal-sized caged cylindrical bearing with more tolerance to heat and thermal cycling. RPM limits are reduced compared to caged roller bearings. Cylindrical bearings do not support axial loads but significantly increase L10 life for the same radial load compared to a deep groove bearing. A secondary bearing on the shaft must be used to accept axial force, or the axial forces must be balanced to prevent movement at the cylindrical bearing.
